TVS Raider Super Squad Edition
Photos (1)
TVS • Raider Model Page • Commuter

TVS Raider Super Squad Edition

Detailed Specifications, Features & Ex-Showroom Price in India

₹ 1.03 Lakh

Ex-Showroom Price

Compare Variant Calculate EMI All 6 Variants
Engine / Motor
124.8cc
Fuel Type
Petrol
Transmission
Manual
Mileage / Range
56.7kmpl

TVS Raider Super Squad Edition Technical Specifications

Click any category below to view detailed specifications

Fuel Type Petrol
Engine Displacement 124.8cc
Vehicle Style Commuter
Seating Capacity 2 Persons
Max Power 11.2 bhp @ 7500 rpm
Max Torque 11.2 Nm @ 6000 rpm
Kerb Weight 123 kg
Warranty 5 year Years / 60000 km
Engine Type 1 cylinder
Displacement 124.8cc
Number of Cylinders 1
Valves Per Cylinder 3 Valves
Max Power 11.2 bhp @ 7500 rpm
Max Torque 11.2 Nm @ 6000 rpm
Cooling System Air/Oil Cooled
Fuel Supply Electronic Fuel Injection (EFI)
Transmission / Gearbox Manual
Number of Gears 5 Speed Speed
Official Mileage 56.7kmpl
Fuel Tank Capacity 10 litres
Emission Standard BS6 Phase 2
Overall Length 2070 mm
Overall Width 785 mm
Overall Height 1028 mm
Wheelbase 1326 mm
Ground Clearance 180 mm
Seat / Saddle Height 780 mm
Kerb Weight 123 kg
Under-seat Storage / Boot N/A Litres
Front Suspension 5- Step Adjustable Monoshock Suspension
Rear Suspension Hydraulic Dual Shock Absorbers / Monoshock
Chassis Frame Type High Rigid Tubular Underbone Frame
Suspension Adjustability Step Adjustable Preload
Front Brake Type Discs
Front Brake Diameter 240 mm mm
Rear Brake Type Drum
Rear Brake Diameter 130 mm mm
Wheel Type Alloys
Front Tyre Size 80/100-17
Rear Tyre Size 100/90-17
Tyre Type Tubeless
Headlight All-LED Projector Headlamp
Tail Light LED
Daytime Running Lights (DRLs) Integrated LED DRLs
Turn Indicators LED Clear Lens Indicators
Pass Light Switch Available
Battery Voltage 12V Maintenance Free Battery
Braking Safety NO
Digital Console YES
Bluetooth Connectivity Available
Internet / App Connectivity NO
Turn-by-Turn Navigation Supported
USB Fast Charging Port Standard
Side Stand Engine Cut-off Yes
Keyless Ignition / Push Button Available
